Sensor amplifier
- A low-noise amplifier common to a “micro force sensor” and a “high-rigidity sensor”
- Designed to be directly connected with the respective sensor head, and output a voltage signal proportional to the pressure.
- Up to two axes can be connected to the amplifier.
| Model number | FSA201C | FSA202C | FSA201S | FSA202S |
|---|---|---|---|---|
| Sensor type | Capacitive displacement sensor | Type for a strain gauge sensor | ||
| Number of axes for connection | 1axis | 2axes | 1axis | 2axes |
| Output voltage | 0 ～ 10V | |||
| Offset adjustment | approximately ±1V | |||
| Outside dimensions | 74.5(W)×287(D)×120(H) mm | |||
| Power source | AC100～120V / AC200～240V Switchable way、 50/60Hz | |||
